HB-SBRS-(4X)GR
Semi-rigid heat shrink tubing with adhesive layer HB-SBRS- (4X) GR is designed to protect welded seams from environmental influences.
Operating temperature: -45 ℃ to 125 ℃
Shrinkage temperature: 125 ℃
Colors: black
Shrinkage factor - 4
Halogen free
Packing: spool and slice
| Outer technical indicators |
||
| performance | index | experiment method |
| Tensile Strength | ≥10.4 MPa | ASTM D 2671 |
| Elongation at break | ≥200% | ASTM D 2671 |
| Strength after heat aging | ≥7.3 MPa | 175℃×168h |
| Elongation at break after heat aging | ≥100% | 175℃×168h |
| Axial change rate | -8%~+8% | ASTM D 2671 |
| Flame retardant | 通过 | ASTM D 2671 B 法 |
| Thermal shock | 无裂纹、无滴落 | ASTM D 2671，250℃×4h |
| Cold-formed flexibility | 无裂纹 | ASTM D 2671，-45℃×4h |
| Water absorption | ≤0.50% | ASTM D 570 |
| Breakdown strength | ≥15kV/mm | IEC 60243 |
| Volume resistivity | ≥1014 Ω·cm | IEC 60093 |
| Hot melt adhesive technical indicators | ||
| performance | index | experiment method |
| Softening Point | 95±5℃ | ASTM E 28 |
| Water absorption | ＜0.5% | ASTM D 570 |
| Peel strength (PE) | ≥120N/25mm | ASTM D 1000 |
| Peel strength (Al) | ≥80N/25mm | ASTM D 1000 |
| ID | Size | Expanded | After Recovery | Standard Package | |||
| Inch | mm | Internal Diameter (mm) | Internal Diameter (mm) | Total Wall Thickness (mm) | Adhesive Thickness (mm) | Spool Length M/spool | |
| HB-SBRS-(4X)GR 4 | 2/13 | 4 | 4 | 0,95 | 1,40±0,30 | 060±0,10 | 200 |
| HB-SBRS-(4X)GR 6 | 1/4 | 6 | 6 | 1,27 | 1,70±0,30 | 0,80±0,10 | 100 |
| HB-SBRS-(4X)GR 8 | 5/16 | 8 | 8 | 1,65 | 2,00±0,30 | 0,95±0,10 | 100 |
| HB-SBRS-(4X)GR 12 | 1/2 | 12 | 12 | 2,41 | 2,45±0,40 | 1,20±0,20 | 1,22 OR 25M/Roll |
| HB-SBRS-(4X)GR 18 | 3/4 | 18 | 18 | 4,45 | 2,60±0,40 | 1,40±0,20 | 1,22 OR 25M/Roll |
