HB-SBRS-(4X)GRF
Non-flammable heat shrink tubing with adhesive HB-SBRS- (4X) GRF. A special feature is a non-flammable adhesive layer. It is used in products with an increased requirement for flame retardancy. Resistant to oils and kerosene. The semi-rigid tube provides additional protection against abrasion and mechanical stress.
Operating temperature: -45 ℃ to 125 ℃
Shrinkage temperature: 125 ℃
Colors: black
Shrinkage factor - 4
Packing: spool and slice
| Property | Test method | Standard | Typical Performance |
|---|---|---|---|
| Tensile strength(MPa) | ASTMD 2671 | ≥10.4 | 11,5 |
| Elongation(%) | ASTMD 2671 | ≥300 | 450 |
| Tensile strength after aging(MPa) | UL224 158℃*168hr | ≥7.3 | 8,5 |
| Elongation after aging (%) | UL224 158℃*168hr | ≥200 | 350 |
| Dielectric strength(kV/mm) | IEC 60243 | ≥15 | 17,5 |
| Volume resistivity(Ω.cm) | IEC 60093 | ≥1*1014 | 2.5*1014 |
| Size | Expanded | After Recovery | Standard Package | |||
|---|---|---|---|---|---|---|
| mm | Internal Diameter(mm) | Internal Diameter(mm) | Total Wall Thickness (mm) | Adhesive Thickness(mm) | Spool Length M/spool | |
| HB-SBRS-(4X)GRF 4 | 4 | 4 | 0,95 | 1.40±0.20 | 0.50±0.10 | 200 |
| HB-SBRS-(4X)GRF 6 | 6 | 6 | 1,27 | 1.70±0.20 | 0.60±0.10 | 100 |
| HB-SBRS-(4X)GRF 8 | 8 | 8 | 1,65 | 2.00±0.20 | 0.75±0.10 | 100 |
| HB-SBRS-(4X)GRF 12 | 12 | 12 | 2,41 | 2.45±0.20 | 1.20±0.20 | 1.22 or 25M/Roll |
| HB-SBRS-(4X)GRF 18 | 18 | 18 | 4,45 | 2.60±0.20 | 1.40±0.20 | 1.22 or 25M/Roll |
